900MHz 2GGSM Signal Booster 900MHz Mobile Phone Signal Repeater

Name: 900MHz 2GGSM Signal Booster 900MHz Mobile Phone Signal Repeater
Brand: vodasafe
Price: 1 USD

Wholesale 900MHz 2GGSM Signal Booster 900MHz Mobile Phone Signal Repeater from china suppliers

Brand Name : vodasafe

Model Number : TE92302

Place of Origin : China

MOQ : 1pcs

Price : Negotialbe

Payment Terms : L/C, T/T, Western Union,

Supply Ability : 5000pcs Per Month

Delivery Time : 3-5Working Days After Payment

Packaging Details : Neutral Packing Carton Box

Power Supply : AC110-220V±10%/45-55Hz

Size : 148mm×106mm×33mm

Reliability : To the GB6993-86 standard

Electromagnetic : To the ETS300 694-4 standard

Function : b) Export power LED denote

Contact Now

900MHz 2GGSM Signal Booster/900MHz Mobile Phone Signal Repeater

Brief Description:

900MHz Pico-Repeater is intended to strengthen the signal of 900MHz mobile phone in the buildings. Ideal for use in areas where the 900MHz signal is weak to cause Call dropout or Cant connection. The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator)

Features:

1. High system gains.

2. Full duplex and double-end design, external power supply, and convenient installation.

3. ALC technology with auto-steady function adopted.

4. Provide power indication and uplink and downlink indications.

5. With the amplified linear power, the inter-modulation an spuriousness are suppressed effectively.

6. The reliability conforms to GB6993-86 standards.

7. The electromagnetic compatibility conforms to ETS300 609-4 standards.

Applicable place:

It can be applied in Building rooms there have weak signal of mobile.

Specification:

Frequency Range	TE-9102B (Uplink: 890-915MHz; Downlink: 935-960MHz)
Gain	(GSM Uplink) Gp≥65dB; (GSM Downlink) Gp≥70dB
Gain adjustable(this function is only for TE923B)	MGC≥30dB
Output Power	TE-9102B ≥23dBm
Pass band ripple	GSM≤5dB
Guard band rejection	GSM (BW-60dB) ≤42MHz
Guard band rejection	GSM (BW-70dB) ≤45MHz
I/O impedance	50Ω/N Connector
I/O return loss	≤-8dB
Noise figure	≤-8dB
Inter-modulation attenuation(Po=13dBm)	≤-40dBm
Transmission	≤0.5μs
Ambient	-10℃-50℃
Power Supply	AC110-220V±10%/45-55Hz
Size	148mm×106mm×33mm
Reliability	To the GB6993-86 standard
Electromagnetic	To the ETS300 694-4 standard
Function	a) Power supply LED denote
	b) Export power LED denote

900MHz 2GGSM Signal Booster 900MHz Mobile Phone Signal Repeater
